VST-HDT Basic 2-3
Three station machine for small measuring batches and ideal for teaching purposes due to manual test set up
The Basic VST / HDT is a cost-effective and compact entry-level tester for determining the VICAT softening temperature and the heat deflection temperature / heat distortion temperature. Manual measurements can be carried out in accordance with international standards. The measurement data acquisition and data evaluation takes place via PC with the Coesfeld WIN software.
Features
Simple and compact set-up
Intuitive WIN-Software
Scaleable from 1 to 3 measuring stations
Specification
|
Temperature |
+30 °C to +300 °C |
|
Digital displacement gauges, resolution |
0.001 mm |
|
Cooling connection |
1/2 '' |
|
Dimensions (W x D x H) |
500 x 580 x 480 mm |
|
Weight |
31 kg |
|
Mains |
230 V, 50/60 Hz, 2000 VA |
