The measurement of creep behavior provides data for design purposes as well as for research and development. The test is performed on standardized test specimens under specified conditions, such as pretreatment, temperature and humidity. DIN EN ISO 899 or ASTM D 2990 describe the creep test on plastics for the tensile test and the flexure test. Dead load / lever systems are characterized by simplicity and are suitable for true long-term measurements. With a movable camera system, cost-effective multi-station systems can be created.

Features

Cost-effective multi station systems possible
Test Load up to 500 N
Movable Camera System (optional)

Specification

Maximum Test Load	500 N / 5 kN
Load Application	Dead Load/ Lever 10:1
Travel	100 mm
Travel Measurement Resolution	Optional
Force Measurment Resolution	Optional
Temperature Control	Optional
Temperature Consistency	Optional
Dimensions (D x W x H)	800 x 1040-1820 mm x 2100 mm
Weight	Depending on configuration
Mains	Depending on configuration
